Stock no. |
2020227 |
|
Make |
WEYRAUCH |
|
Type |
SW 32 – G |
|
Year |
|
|
Control |
konventionell – |
|
Storage location |
|
|
Country of origin |
Germany |
|
Delivery time |
kurzfristig – nach Absprache. |
|
Freight basis |
Lieferung ab Lager Günzburg. |
| bore capacity in steel (diameter) | 32 | mm |
| bore depth | 150 | mm |
| arm length | max. 1200 | mm |
| quill stroke | 150 | mm |
| turning speeds | 100 - 2000 | U/min |
| tool adaptor | MK 4 | |
| 510 x 1200 | mm | |
| distance spindle /table | max. 650 | mm |
| machine weight ab. | 2.000 | kg |
| dimensions | 1750 x 1200 x 2400 | mm |
| bore capacity in steel (diameter) | 32 | mm |
| bore depth | 150 | mm |
| arm length | max. 1200 | mm |
| quill stroke | 150 | mm |
| turning speeds | 100 - 2000 | U/min |
| tool adaptor | MK 4 | |
| 510 x 1200 | mm | |
| distance spindle /table | max. 650 | mm |
| machine weight ab. | 2.000 | kg |
| dimensions | 1750 x 1200 x 2400 | mm |
Link to the machine: https://baestlein.com/en/maschine/radial-drilling-machine-weyrauch-sw-32-g/
For you as a service: Up to 60 months without down payment, without residual value, personal advice and individual leasing rate calculations are available upon request.
