Semi-automatic function:
– Vice closes and engine starts
– Saw head lowers for the cut
– Engine shuts off
– Saw head lifts, vice opens
Semiautomatic dynamic system:
Manual lowering of the saw blade to the desired
Position and cycle start via the manual button.
Upper position is saved automatically.
| 36/72 | m/min | |
| 285 | mm | |
| dimensions of saw-band | 2950 x 27 x 0,9 | mm |
| capacity 90 degrees: round | 250 | mm |
| capacity 90 degrees: square | 220 | mm |
| capacity 90 degrees: flat | 280x220 | mm |
| capacity 60 degrees: round | 120 | mm |
| capacity 60 degrees: square | 80 | mm |
| capacity 60 degrees: flat | 140x100 | mm |
| capacity 45 degrees: round | 230/200 | mm |
| capacity 45 degrees: square | 200/170 | mm |
| capacity 45 degrees: flat | 220x200/200x140 | mm |
| total power requirement | 1,5/1,8 | kW |
| Weight | 485 | kg |
| Overall size | 1970x1150x1840 | mm |
5010260
Steuerung: Sonstige
Metal Processing, Saws, Band Saw
