Semi-automatic function:
– Vice closes and engine starts
– Saw head lowers for the cut
– Engine shuts off
– Saw head lifts, vice opens
Semiautomatic dynamic system:
Manual lowering of the saw blade to the desired position and cycle start
over the hand switch. Upper position is saved automatically.
| 36/72 | m/min | |
| capacity 90 degrees: round | 300 | mm |
| capacity 90 degrees: square | 260 | mm |
| capacity 90 degrees: flat | 330x260 | mm |
| capacity 60 degrees: round | 180 | mm |
| capacity 60 degrees: square | 170 | mm |
| capacity 60 degrees: flat | 170x170 | mm |
| capacity 45 degrees: round | 260/200 | mm |
| capacity 45 degrees: square | 250/180 | mm |
| capacity 45 degrees: flat | 270x200/200x160 | mm |
| dimensions of saw-band | 3650x27x0,9 | mm |
| total power requirement | 1,5/1,8 | kW |
| Overall size | 2130x1400x1950 | mm |
| Weight | 670 | kg |
5010311
Steuerung: Sonstige
Metal Processing, Saws, Band Saw
