Pillar Drilling Machine, ALZMETALL Alzstar 40/SV

// Zustand: new
// Metal Processing
// Pillar Drilling Machine

General data


Stock no.	2010757
Make	ALZMETALL
Type	Alzstar 40/SV
Year	Neu
Control	konventionell –
Storage location	Günzburg
Country of origin	Czech Republic
Delivery time	kurzfristig – nach Absprache.
Freight basis	Lieferung ab Lager Günzburg

Technical Details

	40	mm
threading in St 60	M24
threading in GG 20	M30
Short spindle	MK 3
spindle turning speed - stepless	160 - 2250	U/min
Center of spindle to wall or column	293	mm
Column diameter	115	mm
spindle stroke	120	mm
Machine table - usable table surface	514 x 360	mm
T-Slots Amount - Width - Distance	2 x 14 x 224	mm
Distance spindle-table min.	117/701	mm
feed	0,10 + 0,20	mm/U
Motor output	1,45 / 1,9	kW
height of the machine	ca. 1840	mm
weight of the machine ca.	285	kg

Description

	40	mm
threading in St 60	M24
threading in GG 20	M30
Short spindle	MK 3
spindle turning speed - stepless	160 - 2250	U/min
Center of spindle to wall or column	293	mm
Column diameter	115	mm
spindle stroke	120	mm
Machine table - usable table surface	514 x 360	mm
T-Slots Amount - Width - Distance	2 x 14 x 224	mm
Distance spindle-table min.	117/701	mm
feed	0,10 + 0,20	mm/U
Motor output	1,45 / 1,9	kW
height of the machine	ca. 1840	mm
weight of the machine ca.	285	kg

2010757
Steuerung: konventionell
Metal Processing, Drilling maschines, Pillar Drilling Machine
