Standard equipment:
– Lockable main switch with motor protection switch
– Mushroom pushbutton (latching) for EMERGENCY STOP
– Infinitely variable speed adjustment
– Digital speed display
– Feed overload protection
– Protection class IP 54
– Spindle protection with electrical fuse
Item 3
Anchoring parts (set)
Item 12
LED machine light with radially adjustable light beam,
230 volt supply voltage, protection class IP 65
Item 20.1
Tapping device with foot switch, for tapping with stop, max. 6 threads/min.
max. 6 threads/min. (tapping capacity depends on spindle speed)
Item 37.1
Digital drilling depth display
0-point setting (start of drilling)
5-digit LED display, character height 13 mm
Item 50.6
Drilling depth fine adjustment and fixed stop
Setting value 0.1 mm
| Drilling capacity in St 60 | 40 | mm |
| threading in St 60 | M 24 | |
| threading in GG 20 | M 30 | |
| Short spindle | MK 3 | |
| spindle stroke | 120 | mm |
| throat | 293 | mm |
| column diameter | 115 | mm |
| Machine table - usable table surface | 514x360 | mm |
| T-Slots Amount - Width - Distance | 2x14x224 | mm |
| distance spindle /table | 117/701 | mm |
| Spindle Speed | 160-2250 | U/min. |
| weight | 260 | kg |
2010623
