Stock no. |
2010361 |
|
Make |
ALZMETALL |
|
Type |
AX 3/SV |
|
Year |
Neu |
|
Control |
konventionell – |
|
Storage location |
Günzburg |
|
Country of origin |
Germany |
|
Delivery time |
kurzfristig – nach Absprache. |
|
Freight basis |
Lieferung ab Lager Günzburg |
| 40 | mm | |
| M 24 | ||
| M 30 | ||
| spindle turning speed - stepless | 160-2.250 | U/min |
| MK 3 | ||
| spindle stroke | 120 | mm |
| throat | 293 | mm |
| column diameter | 115 | mm |
| 515x360 | mm | |
| distance spindle /table | min./max. 117/701 | mm |
| 2 x 14 x 224 | mm | |
| feed | 0,1 + 0,2 | mm/U |
| Machine height | 1840 | mm |
| weight | 270 | kg |
| 40 | mm | |
| M 24 | ||
| M 30 | ||
| spindle turning speed - stepless | 160-2.250 | U/min |
| MK 3 | ||
| spindle stroke | 120 | mm |
| throat | 293 | mm |
| column diameter | 115 | mm |
| 515x360 | mm | |
| distance spindle /table | min./max. 117/701 | mm |
| 2 x 14 x 224 | mm | |
| feed | 0,1 + 0,2 | mm/U |
| Machine height | 1840 | mm |
| weight | 270 | kg |
Link to the machine: https://baestlein.com/en/maschine/pillar-drilling-machine-alzmetall-ax-3-sv-3/
For you as a service: Up to 60 months without down payment, without residual value, personal advice and individual leasing rate calculations are available upon request.
