Standard equipment:
– Number of speed ranges 9×2 steps
– Coolant device in the machine base
– Movable LED machine light
– Swivel work table with integrated machine vice on the opposite side
opposite side with jaw width 120 mm
– Mains cable and plug therefore immediately ready for use
– Drilling table adjustable via gear rack
– Depth stop with scale
– Emergency stop
– According to current CE conformity
| 32 | ||
| bore stroke | 125 | mm |
| Short spindle | MK 3 | |
| throat | 210 | mm |
| Machine table - usable table surface | 390x390 | mm |
| table load | 65 | kg |
| spindle turning speed range | 105-2.650 | UpM |
| total power requirement | 0,75 | kW |
| Overall size | 750x450x1745 | mm |
| weight of the machine ca. | 192 | kg |
2010518
Steuerung: Sonstige
Metal Processing, Boring mills / Machining Centers / Drilling machines, Pillar Drilling Machine
