Pillar Drilling Machine, ZIMMER BMS 32 V

// Zustand: new
// Metal Processing
// Pillar Drilling Machine

General data


Stock no.	2010517
Make	ZIMMER
Type	BMS 32 V
Year	Neu
Control	Sonstige –
Storage location	Factory
Country of origin	Germany
Delivery time	nach Absprache.
Freight basis	Lieferung ab Werk.

Technical Details

	32
bore stroke	125	mm
Short spindle	MK 3
throat	210	mm
Machine table - usable table surface	390x390	mm
table load	65	kg
spindle turning speed range	150-2.500	UpM
Power requirement	16	A
total power requirement	1,5	kW
Overall size	750x450x1745	mm
weight of the machine ca.	187	kg

Description

Standard equipment:
– Stepless speed adjustment
– Coolant device in the machine base
– Movable LED machine light
– Swivel work table with integrated machine vice on the opposite side
opposite side with jaw width 120 mm
– Mains cable and plug ready for immediate use
– Drilling table adjustable via gear rack
– Depth stop with scale
– Emergency stop
– According to current CE conformity

	32
bore stroke	125	mm
Short spindle	MK 3
throat	210	mm
Machine table - usable table surface	390x390	mm
table load	65	kg
spindle turning speed range	150-2.500	UpM
Power requirement	16	A
total power requirement	1,5	kW
Overall size	750x450x1745	mm
weight of the machine ca.	187	kg

2010517
Steuerung: Sonstige
Metal Processing, Boring mills / Machining Centers / Drilling machines, Pillar Drilling Machine

Link to the machine: https://baestlein.com/en/maschine/pillar-drilling-machine-zimmer-bms-32-v/
