Accessories / Equipment:
– Three driven rollers
– Hydraulic delivery of the upper roller
– Working position horizontal and vertical
– Digital display with memory function
– Bearings with tapered roller bearings
– Use of replaceable slide rails on the guide carriage
– The standard roller set is included. It can bend various profiles flat iron, T-iron, solid material etc.
| shaft diameter | 60 | mm |
| Shaft revolutions | 6 | U/min |
| roll diameter | 215 | mm |
| pressure hydraulic cylinder | 180 | kN |
| dimensions | 1125x870x1620 | mm |
| weight | 820 | kg |
4040225
Steuerung: Sonstige
Metal Processing, Sheet metal working / shaeres / bending, Pipe-Bending Machine
