Stock no. |
4040241 |
|
Make |
AK-BEND |
|
Type |
AHS 30/08 |
|
Year |
NEU |
|
Control |
NC – |
|
Storage location |
Factory |
|
Country of origin |
Turkey |
|
Delivery time |
nach Absprache. |
|
Freight basis |
Lieferung ab Werk. |
| sheet width | 3100 | mm |
| plate thickness | 10 | mm |
| pre-bending | 8 | mm |
| upper roll diameter | 270 | mm |
| lower roll diameter | 250 | mm |
| side roll diameter | 210 | mm |
| total power requirement | 11 | kW |
| weight of the machine ca. | 7750 | kg |
| Overall size | 5600x1450x1600 | mm |
| sheet width | 3100 | mm |
| plate thickness | 10 | mm |
| pre-bending | 8 | mm |
| upper roll diameter | 270 | mm |
| lower roll diameter | 250 | mm |
| side roll diameter | 210 | mm |
| total power requirement | 11 | kW |
| weight of the machine ca. | 7750 | kg |
| Overall size | 5600x1450x1600 | mm |
Link to the machine: https://baestlein.com/en/maschine/plate-bending-machine-4-rolls-ak-bend-ahs-30-08/
For you as a service: Up to 60 months without down payment, without residual value, personal advice and individual leasing rate calculations are available upon request.
