Includes DORNER 2200 Series conveyor belt
Operating hours:
– Approx. 7,880 h
Standard equipment:
– Travelling ball-bearing tables
– Linear magazine for tool stations and clamping jaws
– 22 tool stations, 3 clamping jaws
– Foot switch for closing the jaws
– Flap for stamped parts 500 x 500 mm incl. sensor
– Chip container
– 2 good parts containers (stamping and laser side)
– Initial fill of hydraulic oil
– FocusLine
– NitroLine
– FastLine
– Additional Xp and Yp axes
– Ejection cylinder for laser parts
– High-speed flap for laser parts 500 x 500 mm incl. sensor
– Liftable laser cutting table
– Liftable laser cutting table
– Slag cone detection
TRUMPF Laser:
– CO2 laser TruFlow 2700 incl. LensLine and optimized StandBy
– Maintenance-free turbo radial blower
– High-frequency excitation
– TASC laser control
Cutting head:
– Lens cutting head with 170 mm lens
– Universal quick-change device (UTI) with bus connection
– ControlLine
Punching head:
– Electro-hydraulic punching head
– Hydraulic single-tool holder with 360° rotation
– Programmable hold-down device (active/passive/re-adjustment)
– Tool length compensation
– Spray lubrication for punch
– Punching scrap extraction
– Level monitoring for thread forming and tool lubrication
Control system:
– Open control system based on Rexroth IndraMotion MTX
– 15″ TFT color screen
– Teleservice via the Internet
– Automatic shutdown
– Production plan
Data transfer
– USB interface
– RJ45 network connection
Safety:
– CE marking
– Dual-beam safety light curtains
– Emergency stop
| Punching capacity | 220 | kN |
| laser capacity in Watt | 4000 | |
| travel -x axis | 2500 | mm |
| travel -y axis | 1250 | mm |
| Cutting capacity structural steel | 8 | mm |
| Cutting capacity stainless steel | 8 | mm |
| Cutting capacity aluminum | 6 | mm |
| workpiece weight | 280 | kg |
| weight of the machine ca. | 24.000 | kg |
| dimensions | 10130 x 8898 x 2328 | mm |
4052098
Steuerung: CNC
Metal Processing, Stamping press, Punch-Laser-Combination
