Equipment:
– Taper bending device
– Swing-out top roller
– Motorized up and down movement of the rear roller,
Up and down movement of the lower rollers by handwheel
– St-52 steel construction housing
– Separate foot pedal for control
– Driven by electric motor + planetary gearbox
– Hardened rollers
– CE conformity
OPTIONAL:
Motorized up and down movement of the bottom roller
– Digital display to show the positions of the rear roller
– Double speed motor
– Variable rotation speed
– Special clamping
– Extended rollers
– Profile rollers
| sheet width | 3050 | mm |
| plate thickness | 6 | mm |
| pre-bending | 5 | mm |
| upper roll diameter | 220 | mm |
| total power requirement | 2,2 | kW |
| weight of the machine ca. | 4000 | kg |
| dimensions of the machine ca. | 5200 x 1150 x 1400 | mm |
4040372
Steuerung: Sonstige
Metal Processing, Sheet metal working / shaeres / bending, Rolls bending machine – 3 Rolls
