Stock no. |
4051372 |
|
Make |
AK-BEND |
|
Type |
SRH 500 |
|
Year |
Neu |
|
Control |
Sonstige – |
|
Storage location |
Factory |
|
Country of origin |
Turkey |
|
Delivery time |
kurzfristig – nach Absprache. |
|
Freight basis |
Lieferung ab Werk. |
| table diameter | 715 | mm |
| table load | 500 | kg |
| Frontal Loading Center (A) | 150 | mm |
| Side Loading Center (B) | 150 | mm |
| Rotating speeds | 0,1 - 1 | UpM |
| T-slots | 6 x M16 | |
| Tilt Angle | 90-180-110 | ° |
| Tilting Speed | 30 | sn min./90° |
| weight of the machine ca. | 675 | kg |
| table diameter | 715 | mm |
| table load | 500 | kg |
| Frontal Loading Center (A) | 150 | mm |
| Side Loading Center (B) | 150 | mm |
| Rotating speeds | 0,1 - 1 | UpM |
| T-slots | 6 x M16 | |
| Tilt Angle | 90-180-110 | ° |
| Tilting Speed | 30 | sn min./90° |
| weight of the machine ca. | 675 | kg |
Link to the machine: https://baestlein.com/en/maschine/rotary-welding-table-ak-bend-srh-500/
For you as a service: Up to 60 months without down payment, without residual value, personal advice and individual leasing rate calculations are available upon request.
