Standard equipment:
– Digital speed display
– Movable LED machine light
– Stepless spindle speed via frequency converter
– Tiltable work table +/- 45 degrees
– Mains cable and plug so ready for immediate use
– Drilling table adjustable via gear rack
– Depth stop with scale
– Emergency stop
– In accordance with current CE conformity
| 23 | ||
| thread capacity | M10 | |
| bore stroke | 90 | mm |
| Short spindle | MK2 | |
| throat | 180 | mm |
| Machine table - usable table surface | 285x285 | mm |
| table load | 45 | kg |
| spindle turning speed range | 150-1.250/350-3.000 | UpM |
| total power requirement | 0,75 | kW |
| Overall size | 735x470x1080 | mm |
| weight of the machine ca. | 106 | kg |
2010520
Steuerung: Sonstige
Metal Processing, Boring mills / Machining Centers / Drilling machines, Bench Drilling Machine
