Stock no. |
4021360 |
|
Make |
GPRESS |
|
Type |
GHT 420 x 5000 |
|
Year |
NEU |
|
Control |
CNC – Cybelec VisiTouch 24 |
|
Storage location |
Factory |
|
Country of origin |
China |
|
Delivery time |
nach Absprache. |
|
Freight basis |
Lieferung ab Werk. |
| pressure | 420 | t |
| chamfer lenght | 5100 | mm |
| distance between columns | 4600 | mm |
| Control | Cybelec VisiTouch 24 | |
| throat | 500 | mm |
| stroke | 400 | mm |
| dayligth | 600 | mm |
| 110 | mm/s | |
| bending speed | 0-8 | mm/s |
| total power requirement | 32 | kW |
| weight of the machine ca. | 38.000 | kg |
| dimensions | 5850xx2850x4420 | mm |
| pressure | 420 | t |
| chamfer lenght | 5100 | mm |
| distance between columns | 4600 | mm |
| Control | Cybelec VisiTouch 24 | |
| throat | 500 | mm |
| stroke | 400 | mm |
| dayligth | 600 | mm |
| 110 | mm/s | |
| bending speed | 0-8 | mm/s |
| total power requirement | 32 | kW |
| weight of the machine ca. | 38.000 | kg |
| dimensions | 5850xx2850x4420 | mm |
Link to the machine: https://baestlein.com/en/maschine/hydr-pressbrake-gpress-ght-420-x-5000/
For you as a service: Up to 60 months without down payment, without residual value, personal advice and individual leasing rate calculations are available upon request.
