piston compressor, SCHNEIDER UNM 580-15-90 D

// Zustand: new
// Other Accessories for Machine Tools
// piston compressor

General data


Stock no.	4050953
Make	SCHNEIDER
Type	UNM 580-15-90 D
Year	NEU
Control	Sonstige –
Storage location	Factory
Country of origin
Delivery time	nach Absprache.
Freight basis	Lieferung ab Werk.

Technical Details

Suction	580	l/min.
Filling capacity	470	l/min
On / switch-off	13/15	bar
Heads / stages	2/2
container volume	90	l
voltage	400 V / 50 Hz
engine output	4	kW
turning speeds	915	U/min
Sound power level	95	dB
dimensions	1110 x 495 x 1000	mm
weight	111	kg

Description

– easy to move thanks to castors and long handle
– mobile, V-belt driven piston compressor
– Compressor for work up to 15 bar
– equipped with filter pressure reducer

Suction	580	l/min.
Filling capacity	470	l/min
On / switch-off	13/15	bar
Heads / stages	2/2
container volume	90	l
voltage	400 V / 50 Hz
engine output	4	kW
turning speeds	915	U/min
Sound power level	95	dB
dimensions	1110 x 495 x 1000	mm
weight	111	kg

4050953
Steuerung: Sonstige
Other Accessories for Machine Tools, Other Accessories for Machine Tools etc., piston compressor
