Standard equipment:
– Knife set for flat steel
– Complete knife set for angle steel shears
– Complete normal punching equipment
– Quick release device for punches up to 31 mm
– Support table for punching device, rectangular notching and flat steel shears
– Bending stamp with matrices V 40 and V 70
– Electric contact stop (1.000 mm)
| flat steel | 350 x 15 | mm |
| round bar steel | 35 | mm |
| square edge steel | 30 | mm |
| L-beam | 80x80x8 | mm |
| hole diameter in sheet thickness | Ø 27 in 13 / Ø 20 in 18 | mm |
| blade length | 356 | mm |
| engine output | 3.0 | kW |
| Stroke rate | 34 | |
| Punching capacity | max. 500 | kN |
| weight | 950 | kg |
| dimensions | 1300x1100x1850 | mm |
10067
Steuerung: Sonstige
Metal Processing, Sheet metal working / shaeres / bending, Section Steel Shear
