Standard equipment:
– Electromagnetic feed clutch with overload protection and electrical
Cross Handle Switches
– Control and light transformer
– Main switch lockable
– Mushroom pushbutton (latching) for EMERGENCY STOP in the front panel
– Clockwise rotation by contactor control
– Speed adjustment stepless
– Speed display digital
– Speed setting electrically
– Protection IP 54
– Motor insulation class “F”
– Spindle protection with electrical protection
Pos. 12
LED machine lamp with radially adjustable light beam, supply voltage 24
Volt, protection class IP 65
Pos. 20.1
Tapping device with foot switch, for thread cutting with
Stop, max. 6 threads / min (tapping power dependent on spindle speed)
Pos. 24
Coolant device A consisting of: Coolant base plate with machined
Workpiece support surface 320×320 mm and 2 flutes, pump with
Motor protection switch and complete fitting
| 50 | mm | |
| bore capacity in cast iron | 56 | mm |
| 50 | mm | |
| M 30 | ||
| M36 | ||
| MK 4 | ||
| throat | 300 | mm |
| 615x430 | mm | |
| 70-4000 | U/min. | |
| 2x14x224 | mm | |
| Distance spindle/table max. | 147/688 | mm |
| column diameter | 145 | mm |
| spindle stroke | 160 | mm |
| feeds | 0,1-0,4 | mm/U |
| height of the machine | 1885 | mm |
| drive motor | 1,8/2,9 | kW |
| weight of the machine ca. | 530 | kg |
2010761
Steuerung: konventionell
